Double bucket granule packaging machine

Product introduction:

The HK-KS50B double-bucket granule packaging machine is mainly composed of four parts: automatic quantitative device, conveying device, sewing device, and computer control system. It is a new generation of intelligent packaging machine newly developed by Zhengzhou Hanke Machinery, with reasonable structure, beautiful electrostatic spraying process, stable operation, easy operation, fast weighing speed, and accurate measurement.

The main machine adopts arc door feeding mechanism, A and B double buckets automatically discharge materials alternately, anti-interference technology, and realizes automatic error compensation and correction.

Structural composition:

The double-bucket granule packaging machine is mainly composed of the following key parts:

Double bucket structure: The equipment is equipped with two weighing buckets A and B, which can alternately discharge materials to improve packaging efficiency.

Automatic quantitative device: Through high-precision sensors and intelligent weighing controllers, accurate granular material measurement is achieved.

Conveying device: usually includes belt conveyors or screw conveyors, etc., which are used to transport the measured granular materials into the packaging bags.

Sealing device: The packaging bags are heat-sealed or sewn to ensure that the fertilizer will not leak and keep the packaging bags beautiful and strong.

Control system: usually based on PLC technology, to achieve automatic control and operation of equipment, including parameter setting, fault self-diagnosis and other functions.

Working principle:

The working principle of the double bucket granule packaging machine is as follows:

The granular material flows into the A weighing hopper through the feed port, and the control system starts metering at the same time.

When the granular material in the A weighing hopper reaches the preset value, the control system will stop feeding, open the discharge door under the weighing hopper, and instantly load the granular material into the bag.

At this time, the A weighing hopper stops working, and the B weighing hopper starts to repeat the above steps. The two weighing hoppers are carried out alternately to achieve continuous packaging operations.

The measured granular material is transported to the sealing device through the conveying device for sealing.

The sealed packaging bag is sent to the stacking area through the conveyor belt, and the stacking robot or manual stacking is performed.

Scope of application:

The double bucket granule packaging machine is widely used in fertilizer production, processing and packaging industries. It is suitable for granular materials with good fluidity and uniform particle size, such as snow melting agent, compound fertilizer, blended fertilizer, organic fertilizer granules, urea, rubber granules, plastic granules, biomass granules, refractory materials, corundum, corn, wheat, soybeans, peanuts, etc. .

Features and advantages:

High efficiency: The double bucket structure enables the equipment to carry out packaging operations continuously, greatly improving production efficiency.

Accuracy: High-precision sensors and intelligent weighing controllers ensure that the weight of granular materials in each packaging bag is accurate.

Ease of operation: The equipment usually adopts a PLC control system, which is simple and intuitive to operate, reducing the labor intensity of workers.

Durability: The equipment is made of high-quality materials such as stainless steel, and has the characteristics of corrosion resistance and wear resistance, and has a long service life.

In summary, the double bucket granule packaging machine is an efficient, accurate, easy-to-operate and durable automatic packaging equipment, which is widely used in the packaging industry of fertilizers and other solid granular materials.
